Style 5910
USER CHANGEABLE COLOR is standard on all BRG LED digital clocks.
BRG Time Zone Clocks are accurate for life without the need for manual or external time updates. A GUI touch screen IR remote control is available to ease configuration.
Time Zone Display Programmable Style 5910
Model 5910J - featuring user changeable color dot matrix
LEDs
| Introducing BRG's New Time Commander Graphical Remote Control Programmer Option. Recommended for Programmable Alpha Time Zone Clocks. | |
 Click for more information |
The Time Commander is only compatible with BRG Time Zone Clocks Manufactured after October 2018 |
| The 5910 series LED digital world
time zone clocks have 10 character dot matrix LED time displays with a 15
character dot matrix digital zone label below. More zones may be displayed than physically available by page flipping to another set of zones – For example, a 5 zone display can actually display up to 20 zones by page flipping through 4 sets of zones. Selected zones can remain constant while other zones change. |
 |
You may choose between 12 or 24 hour time formats. Date formats include numeric, three character alpha-numeric month, day of month, day of week, day of the year, and four digit year.
Now with 3X more LED's than competing products! Call 866-252-2704 or 316-530-8854 |
|
|
All products listed below are available on GSA Advantage, except the Blue LED Clocks. Call our Sales team for GSA Pricing.
|
|
Available Options for the 5910 Time Zone Clock |
||
| Computer Interface and Time Sync Options | ||
| Option | Unit | Description |
| EN | Per Clock | Ethernet Interface (NTP time sync and UDP parameter control) |
| GP | Per Clock | GPS Atomic Time Receiver (Indoor or Outdoor Mount) |
| PC | Per Clock | PC Serial Port Interface (RS232/422 Converter) |
| RC | Per Clock | DuraTime 2.4 GHz Radio Transceiver for synchronization or parameter control |
| SB | Per Clock | IRIG-B / SMPTE Receiver |
| WF | Per Clock | Wi-Fi Receiver |
| SR-ST | Per Clock | Serial Wire Sync Receive / Transmit |
| ST | Per Clock | Serial Wire Sync Transmit |
| Call 866-252-2704 or 316-530-8854 for questions and assistance | ||
| Misc Options | ||
| Option | Unit | Description |
| AB | Per Clock | Auto Brightness |
| M16 | Per Zone | Add 1.8" Seconds display to one zone |
| M26 | Per Zone | Add 2.5" Seconds display to one zone |
| M46 | Per Zone | Add 2.5" Seconds display to one zone |
| TS | Per Clock | Add a temperature senor to one zone |
| TM | Per Clock | Add Timer and IR receiver to time zone clock |
| PM2 | Per Clock | Double Pole Mount for ceiling mounting |
| Remote Control Options | ||
| Option | Description | |
| IR1 | The infrared remote control is included with the purchase of a time zone clock | |
| USB-IR | IR dongle for your PC that allows you to control the time zone clock can be substituted of the IR1 Remote | |
| IR1LR | Long Range IR Remote with 100 ft. range | |
| TC | Time Commander graphical IR remote control | |
| Power Configuration Options | ||
| Option | Description | |
| P0812 | 12 ft. power cord with US Plug (Default) | |
| P0808 | 8 ft. power cord with US Plug | |
| P11 | 8.5 ft. power cord with UK Plug | |
| P16 | 8.5 ft. power cord with Euro Plug | |
| P12 | 6.5 ft. power cord with Australian Plug | |
The 5910 Models
| Model | Phy. Pos. |
Maximum | Time |
Label |
Viewing Distance | Inches | Buy a Multi-Color LED Clock Online or order through GSA Advantage. GSA orders please call with zone labels |
|||||||
| Pages | Zones | Size | Digits | Size | Digits | H | W | |||||||
1.2" Red, Blue, Green, Yellow, Magenta, Cyan or White LEDs |
||||||||||||||
| 5910B | 2 | 5 | 10 | 1.2" | 10 | 1.2" | 15 | 30 ft. | 7.25 | 36.25 |  |
 |
 |
|
| 5910C | 3 | 3 | 9 | 1.2" | 10 | 1.2" | 15 | 30 ft. | 7.25 | 54.25 |  |
 |
|
|
| 5910D | 4 | 2 | 8 | 1.2" | 10 | 1.2" | 15 | 30 ft. | 7.25 | 72.25 |  |
|
|
|
| 5910E | 5 | 2 | 10 | 1.2" | 10 | 1.2" | 15 | 30 ft. | 7.25 | 90.25 |  |
|
|
|
2.0" & 1.2" Red, Blue, Green, Yellow, Magenta, Cyan or White LEDs |
||||||||||||||
| 5910G | 2 | 5 | 10 | 2.0" | 10 | 1.2" | 15 | 70 ft. | 8.25 | 40.25 |  |
|
|
|
| 5910H | 3 | 3 | 9 | 2.0" | 10 | 1.2" | 15 | 70 ft. | 8.25 | 60.25 |  |
|
|
|
| 5910I | 4 | 2 | 8 | 2.0" | 10 | 1.2" | 15 | 70 ft. | 8.25 | 80.25 |  |
|
|
|
| 5910J | 5 | 2 | 10 | 2.0" | 10 | 1.2" | 15 | 70 ft. | 8.25 | 96.25 | |
|
|
|
2.0" Red, Blue, Green, Yellow, Magenta, Cyan or White LEDs |
||||||||||||||
| 5910L | 2 | 5 | 10 | 2.0" | 10 | 2.0" | 15 | 70 ft. | 9.25 | 60.25 |  |
|
|
|
| 5910M | 3 | 3 | 9 | 2.0" | 10 | 2.0" | 15 | 70 ft. | 9.25 | 90.25 |  |
|
|
|
Call 866-252-2704 or 316-530-8854 |
||||||||||||||
Additional Videos
| Model Number | Number of Zones |
Click on button to launch
|
|
All Models
|
Programmable Time Zone Page Flipping Example |
|
| 5910M | 3 Zone Alpha Time Zone Clock with blue 2.0", 10 character dot matrix LEDs for the time and 2.0", 15 character dot matrix LEDs for the zone labels. |
|
| Color Options |
Photo Below is a 6610L with user changeable
multi-color LEDs |
